KLD-PLB SERIES
SAMLL PORTABLE OUTDOOR
MOBILE POWER PACK
350-3600W
Intelligent
Portable
Stable
KLD-PLB SERIES
SAMLL PORTABLE OUTDOOR
MOBILE POWER PACK
350-3600W
The maximum battery capacity of KLD-PLB series small portable outdoor mobile power pack is 3600WH, and its portable design is suitable for all scenarios, such as working outdoor, entertainment, etc.. It supports a variety of charging methods to supply continuous power for computers, cell phones, basic electrical appliances, outdoor work, electric tools and other equipment, and it can also be used as a backup power supply.
Safe guarantee with temperature, charging and discharging, overload, overcurrent and other multiple protections.
It can be used with portable solar panels, perfectly compatible to meet the needs of a variety of scenarios.
Highly stable BMS monitors and controls battery charging and discharging to ensure stable battery operation.
| Model | KLD-PLB350W | KLD-PLB600W | KLD-PLB1000W | KLD-PLB2400W | KLD-PLB3600W |
| Capacity/Wh | 284.7 | 569.4 | 1089 | 2304 | 3600 |
| Rated output power | 350W | 600W | 1000W | 2400W | 3600W |
| AC charging input | 220V-240V 50/60Hz | ||||
| Solar energy input | 11-30V MAX 10A 100W |
11-30V MAX 10A 100W |
11-36V MAX 10A 200W |
11-90V MAX 10A 800W |
11-90V MAX 10A 800W |
| Vehicle charger input | 11-30V MAX 10A 100W |
11-30V MAX 10A 100W |
11-36V MAX 10A 200W |
11-30V MAX 10A 100W |
11-30V MAX 10A 100W |
| USB output | QC3.0/18W 5-12V*2 | 5V.2.4A*2 MAX 12W QC3.0/ 18W 5-12V*2 |
5V.2.4A*4 MAX 12W QC3.0/ 18W 5-12V*2 |
5V.2.4A*4 MAX 12W QC3.0/ 18W 5-12V*2 |
5V.2.4A*4 MAX 12W QC3.0/ 18W 5-12V*2 |
| Wireless charging | MAX 15W | ||||
| TYPE-C output | PD100W | PD100W/PD27W | PD100W/PD27W | PD100W/PD27W | PD100W/PD27W |
| Cigarette lighter output | 12V MAX 10A | 12V MAX 10A | 12V MAX 10A | 12V MAX 10A | 12V MAX 10A |
| DC5521output | 12V MAX 10A | ||||
Note: material download page for detailed parameter
Capacity/Wh：284.7
Rated output power：350W
AC charging input：220V-240V 50/60Hz
Solar energy input：11-30V MAX 10A 100W
Vehicle charger input：11-30V MAX 10A 100W
USB output：QC3.0/18W 5-12V*2
Wireless charging：MAX 15W
TYPE-C output：PD100W
Cigarette lighter output：12V MAX 10A
DC5521output：12V MAX 10A
Capacity/Wh：569.4
Rated output power：600W
AC charging input：220V-240V 50/60Hz
Solar energy input：11-30V MAX 10A 100W
Vehicle charger input：11-30V MAX 10A 100W
USB output：5V.2.4A*2 MAX 12W QC3.0/18W 5-12V*2
Wireless charging：MAX 15W
TYPE-C output：PD100W/PD27W
Cigarette lighter output：12V MAX 10A
DC5521output：12V MAX 10A
Capacity/Wh：1089
Rated output power：1000W
AC charging input：220V-240V 50/60Hz
Solar energy input：11-36V MAX 10A 200W
Vehicle charger input：11-36V MAX 10A 200W
USB output：5V.2.4A*4 MAX 12W QC3.0/18W 5-12V*2
Wireless charging：MAX 15W
TYPE-C output：PD100W/PD27W
Cigarette lighter output：12V MAX 10A
DC5521output：12V MAX 10A
Capacity/Wh：2304
Rated output power：2400W
AC charging input：220V-240V 50/60Hz
Solar energy input：11-90V MAX 10A 800W
Vehicle charger input：11-30V MAX 10A 100W
USB output：5V.2.4A*4 MAX 12W QC3.0/18W 5-12V*2
Wireless charging：MAX 15W
TYPE-C output：PD100W/PD27W
Cigarette lighter output：12V MAX 10A
DC5521output：12V MAX 10A
Capacity/Wh：3600
Rated output power：3600W
AC charging input：220V-240V 50/60Hz
Solar energy input：11-90V MAX 10A 800W
Vehicle charger input：11-30V MAX 10A 100W
USB output：5V.2.4A*4 MAX 12W QC3.0/18W 5-12V*2
Wireless charging：MAX 15W
TYPE-C output：PD100W/PD27W
Cigarette lighter output：12V MAX 10A
DC5521output：12V MAX 10A
